Connections

20+4-pin mainboard

1x 650 mm

4+4-pin mainboard 12V (8-pin EPS)

2x 650 mm

PCI-Express 5.1 12+4-Pin

1x 600 mm

PCI-Express 6+2-Pin

2x 675 mm / 2x 750 mm

SATA

3x 500 mm / 3x 650 mm / 2x 800 mm / 2x 950 mm

PATA

1x 350 mm / 2x 500 mm / 1x 650 mm / 1x 800 mm

+3,3V

20,0 A

+5V

20,0 A

max. combined

100,0 W

+12V

62,4 A

max. combined

748,8 W

Fan

135 mm fan

Certification

80 PLUS® GOLD

PFC

active

Efficiency

up to 90 %

Standby consumption

< 0,5 W

Temperature-dependent control for housing fans

Yes

Safety circuits

OVP (overvoltage protection)
OCP (overcurrent protection)
OPP (overpower protection)
SCP (short-circuit protection)
UVP (undervoltage protection)

Full Range

100 - 240 V

Test mark

CE, TÜV

Material

Metal, plastic

Color

black

Barcode

4262443281033

Manufacturer code

LC6750M V3.1
