ALIMENTATORI / Single/Redundant / LC1200P V3.0

GALLERY

Clicca sull'immagine per ingrandire la gallery

SCHEDA PRODOTTO

Cod./Produtt.: ASM0006/LC1200P V3.0
Produttore: LC-POWER
Descrizione: ALIM. LC-POWER 1200w LC1200 V3.0 - 135mm, 1*20+4 pin, 1*4+4 pin, 1*4 pin, 20x SATA, 2*PCIe 12+4 for GPU, 8* PCIe 6+2, Active PFC, 20A (+5V) 80 Plus Platinum, (92% Efficiency) Cable Management

SPECIFICHE TECNICHE

Power supply type	Platinum series
ATX standard	ATX V3.0
Connections
20+4-pin mainboard	1x 650 mm
4+4-pin mainboard 12V (8-pin EPS)	2x 650 mm
4-pin mainboard 12 V	1x 800 mm
PCI-Express 5.0 12+4-Pin	2x 650 mm
	IMPORTANT: Please only connect a graphics card up to 450 W or 600 W to the power supply unit.
	Alternatively, two graphics cards up to 300 W each can be connected.
PCI-Express 6+2-Pin	8x in total
	(4x 675 mm / 4x 750 mm)
Connection options	Option 1: 20x SATA & 3x PATA
(simultaneous use)	Option 2: 16x SATA & 6x PATA
SATA	20x in total
	(5x 500 mm / 5x 650 mm / 5x 800 mm / 5x 950 mm)
PATA	6x in total
	(2x 500 mm/ 2x 650 mm / 2x 800 mm)
FDD	1x 900 mm
Test mark	CE / TÜV
Fan	135 mm
PFC	active
Power supply unit dimensions	86 x 180 x 150 mm
Packaging dimensions	120 x 295 x 225 mm
Weight (product / total)	3.67 / 4.03 kg
Performance	1200 W
+3,3V	20 A
+5V	20 A
max. combined	100 W
+12V	100 A
max. combined	1200 W
Certified	80 PLUS® PLATINUM
Efficiency	up to 92 %
Standby consumption	< 0.5 W - ErP 2013
Temperature-dependent control for housing fans	Yes
Safety circuits	OVP = overvoltage protection
	OCP = Overcurrent protection
	OPP = overpower protection
	SCP = Short-circuit protection
	UVP = Undervoltage protection
Full range (110V/220V)	Yes
Haswell compatible	Yes
Color	black
Guarantee	3 years
Manufacturer code	LC1200P V3.0
